Quick Release Hose Clamps for securing our polyurethane, PU, PVC and Master Clip range of flexible hoses and ducts.
Product Description
Quick Release Hose Clamps:
Quick Action worm gear drive clamps with special bridge section to prevent twisting of the clamp when securing hose with large external helix.
Properties
• Can be quickly tightened & released using the cam arm
• To suit Left-Hand helix as standard
Applications For Quick Release Hose Clamps
For securing Master Clip ducts, where quick connection and ease of attachment is required
Colour
Silver
Size Range For Quick Release Hose Clamp
Please, see the datasheet below
Options
• Stainless Steel available on request
• To suit Right-Hand helix on request
Downloads
Download Technical Data Sheet
Download Chemical Compatibility Chart
| for Master-Clip hoses in DN | clamping range | article no. |
| mm | mm | |
| 75 | 75-82 | 532-075-0000 |
| 80 | 80-87 | 532-080-0000 |
| 90 | 90-97 | 532-090-0000 |
| 100 | 100-107 | 532-100-0000 |
| 110 | 110-117 | 532-110-0000 |
| 120 | 120-127 | 532-120-0000 |
| 125 | 125-132 | 532-125-0000 |
| 130 | 130-137 | 532-130-0000 |
| 140 | 140-147 | 532-140-0000 |
| 150 | 150-157 | 532-150-0000 |
| 160 | 160-167 | 532-160-0000 |
| 170 | 170-177 | 532-170-0000 |
| 175 | 175-182 | 532-175-0000 |
| 180 | 180-187 | 532-180-0000 |
| 200 | 200-207 | 532-200-0000 |
| 215 | 215-222 | 532-215-0000 |
| 225 | 225-232 | 532-225-0000 |
| 250 | 250-257 | 532-250-0000 |
| 275 | 275-282 | 532-275-0000 |
| 300 | 300-307 | 532-300-0000 |
| 315 | 315-332 | 532-315-0000 |
| 325 | 325-332 | 532-325-0000 |
| 350 | 350-357 | 532-350-0000 |
| 375 | 375-382 | 532-375-0000 |
| 400 | 400-407 | 532-400-0000 |
| 450 | 450-457 | 532-450-0000 |
| 500 | 500-507 | 532-500-0000 |
| 350 | on request | 0.01 |
| 375 | on request | 0.01 |
| 400 | on request | 0.01 |
| 450 | on request | 0.01 |
| 500 | on request | 0.01 |
| 550 | on request | 0.01 |
| 600 | on request | 0.01 |
| 700 | on request | 0.01 |
| 800 | on request | 0.01 |
| 900 | on request | 0.01 |
| All data refers to a medium and ambient temperature of +20 °C. Subject to technical changes and colour deviations. |
||
Product Features
| Diameter Range | 75-500 mm |
| See also different: | Hose Clips (Hose Clamps) |
