Lightweight & Flexible polyurethane street-cleaner wander hoses; being microbe-resistant, abrasion, UV resistant & highly flexible, these are great for street cleaning & precinct sweeping machines.
Product Description
Streetmaster L-F
Description
This suction Wander Hose, Streetmaster L-F, is microbe-resistant, highly flexible and abrasion resistant, good for leaf collecting and street cleaning machines.
• Polyester polyurethane hose
• Reinforced with embedded PVC coated high tensile steel wire helix
• PU thickness of 0.7 mm
Wander Hose Properties
• Very flexible
• Highly abrasion-resistant
• Microbe resistant
Applications
• Suction hose for street cleaning machines (sweeper hose).
• Leaf collecting
• Grass cutting machines
Colour
Black or Clear.
Size Range
100 mm to 300 mm.
Temp Range
-40 ºC to +90 ºC (intermittent to +125 ºC).
Options
• Special diameters
• Other lengths available on request
Streetmaster L-F Hose Data Sheet
Download Masterflex Chemical Resistance Data Sheet
Learn About Street Sweepers/Cleaning Machines
DN | op. pressure | vacuum | bend radius | outer Ø | weight/m | old article no. | new article no. | standard length |
max. production length |
bar | bar | mm | mm | kg | m | m | |||
100* | 0.5 | 0.1 | 75 | 112 | 0.7 | 313-100-x | 007574-100-x | 10 | 15 |
125* | 0.4 | 0.1 | 90 | 135 | 1 | 313-125-x | 007574-125-x | 10 | 15 |
150* | 0.35 | 0.07 | 100 | 160 | 1.2 | 313-150-x | 007574-150-x | 10 | 15 |
160* | 0.35 | 0.07 | 105 | 170 | 1.4 | 313-160-x | 007574-160-x | 10 | 15 |
180* | 0.3 | 0.07 | 120 | 192 | 1.5 | 313-180-x | 007574-180-x | 10 | 15 |
200* | 0.25 | 0.07 | 125 | 212 | 1.6 | 313-200-x | 007574-200-x | 10 | 15 |
225* | 0.25 | 0.07 | 150 | 240 | 1.8 | 313-225-x | 007574-225-x | 10 | 15 |
250* | 0.22 | 0.06 | 200 | 265 | 1.9 | 313-250-x | 007574-250-x | 10 | 15 |
300* | 0.2 | 0.06 | 250 | 315 | 3 | 313-300-x | 007574-300-x | 10 | 15 |
All data refers to a medium and ambient temperature of +20 °C. * Available on request Subject to technical changes and colour deviations. |
Product Features
Maximum Temperature | 130 ºC |
Minimum Wall Thickness | 0.7 mm |
Diameter Range | 100-300 mm |
