Flamex B-F HS: Abrasion-Resistant Suction & Transport Hoses made from PU. Heavy-duty & Hardly Inflammable PU film hose Hoses.
Product Description
Flamex B-F HS:
Material
• Spiral: spring steel wire
• Wall: pure polyester polyurethane
• Wall thickness between spirals approx. 1.4 mm
Applications
• Protective Hose against mechanical wear
• Transport hose for abrasive solids
• Woodworking machines
• Extraction of sawdust and wood-chips
• Flamex B-F HS is also suitable for dust, fumes and powder applications in a wide range of industries
Properties
• Symmetrical fold behaviour
• Very flexible
• Halogen-free
• Optimum flow characteristics
• Compressible to approx. 1:3
• Heavy duty
• Generally good UV and ozone resistance
• High tensile strength
• Highly abrasion-resistant
• Good resistance to chemicals, oil and fuel
Temperature Range
• -40°C to +90°C
• peaks to +125°C
Masterflex Chemical Resistance Sheet
DN | op. pressure | vacuum | bend radius | outer Ø | weight/m | old article no. | new article no. | standard length |
max. production length |
bar | bar | mm | mm | kg | m | m | |||
304* | 0.25 | 0.06 | 300 | 315 | 4 | 310HS-300-x | 007573-300-x | 10 | 15 |
406* | 0.13 | 0.05 | 400 | 418 | 4.8 | 310HS-400-x | 007573-406-x | 10 | 15 |
All data refers to a medium and ambient temperature of +20 °C. * Available on request Subject to technical changes and colour deviations. |
Product Features
Maximum Temperature | 90 °C |
Minimum Wall Thickness | 1.4 mm |
Diameter Range | 304-406 mm |
