PU Hose Sleeve

Product Description

Hose Sleeve

Material

Abrasion-resistant polyurethane

Applications

Reusable special sleeve for connecting spiral hoses from Masterflex SE hose range.

Properties

• lightweight
• microbe-resistant
• shock-proof

Temperature Range
• -40°C to +90°C
• peaks to +125°C

DN hose	Da: outer Ø screw range	total length	for Master Pur hose type	old article no.	new article no.
	mm	mm
38	59	25	L	500-038-107-L	1331
51	67	37	L	500-050-107-L	/
65	87	43	L	500-065-107-L	1342
75	101	43	L	500-075-107-L	/
80	102	43	L	500-080-107-L	1351
102	118	80	L	500-100-107-L	1355
127	147	115	L	500-125-107-L	1360
152	173	133	L	500-150-107-L	1364
204	239	180	L	500-200-107-L	/
38	59	25	H	500-038-107-H	1329
51	67	37	H	500-050-107-H	1335
65	87	43	H	500-065-107-H	1340
75	101	43	H	500-075-107-H	1344
80	101	43	H	500-080-107-H	1348
102	118	80	H	500-100-107-H	1352
127	147	115	H	500-125-107-H	/
152	173	133	H	500-150-107-H	/
204	239	180	H	500-200-107-H	/
51	71	37	HX	500-050-107-HX	1336
65	87	43	HX	500-065-107-HX	/
75	101	43	HX	500-075-107-HX	1345
80	102	43	HX	500-080-107-HX	1349
102	130	80	HX	500-100-107-HX	1353
127	154	115	HX	500-127-107-HX	/
152	180	133	HX	500-150-107-HX	/
204	239	180	HX	500-200-107-HX	1367
38	60	25	Inline	500-038-107-I04	1330
40	61	25	Inline	500-040-107-I04	1333
51	70	37	Inline	500-050-107-I04	1337
65	86	43	Inline	500-065-107-I04	1341
76	101	43	Inline	500-076-107-I04	/
80	101	43	Inline	500-080-107-I04	1350
102	128	80	Inline	500-102-107-I04	/
127	154	115	Inline	500-127-107-I04	/
152	180	133	Inline	500-150-107-I04	1363
#204	239	180	Inline	500-200-107-I04	1368
38	60	25	Performance	500-038-107-P	1332
40	61	25	Performance	500-040-107-P	1334
51	70	37	Performance	500-051-107-P	1339
65	86	43	Performance	500-065-107-P	1343
76	101	43	Performance	500-076-107-P	1347
102	128	80	Performance	500-102-107-P	1356
127	154	115	Performance	500-127-107-P	1361
152	180	133	Performance	500-152-107-P	1365
All data refers to a medium and ambient temperature of +20 °C. Subject to technical changes and colour deviations.
