Spiral-free PU conveying hose, lightweight, permanently antistatic, good flexibility, food-safe EU10/2011 and FDA
Product Description
Construction / Material
- Execution of the wall: made of specified material, Wall thickness approx. 1.0 mm
- Material of the wall: Polyether Polyurethane
- Specifications of the wall: approved for direct food contact according to EU Directive 1935/2004, 10/2011 and its latest amending Directives, Surface resistance R₀ < 10⁹ Ohm, measured according to DIN EN ISO 8031, Material complies with food regulations FDA 21 CFR § 177.2600 – 21 CFR § 178.2010
Properties
- Specifications of the product: Manufacturing process according to GMP EC 2023/2006
- Chemical Properties: good UV resistance, good ozone resistance
- Mechanical Properties: permanently kink-resistant, excellent tensile and tear strength
- Physical Properties: permanently antistatic
- Colour: transparent
- Other: high vacuum and good pressure resistance, particularly smooth on the inside
Operating Temperature
- Temperature Range: -40°C to +90°C
- short-term maximum temperature: peaks at 125 °C
Delivery Information
- Delivery, type of production: Various nominal widths in standard lengths are available ex-production, individual nominal widths and lengths also ex-stock
Application Areas
- Areas of application: Agriculture, Bulk & Construction, Chemistry, Food & Pharma, Plastics
Customizing Options
- optional item modification (on request): other colours, other lengths, other nominal widths, with earth wire, with a customer-specific imprint
Article Variants
| All data refers to a medium and ambient temperature of +20 °C. Subject to technical changes and colour deviations. |
||||
| DN (mm) | weight/m (kg) | article no. | standard length (m) | max. production length (m) |
| 50 | 0.26 | 009111:51:x | 5 | 5 |
| 60 | 0.30 | 009111:60:x | 5 | 5 |
| 70 | 0.33 | 009111:70:x | 5 | 5 |
| 76 | 0.36 | 009111:76:x | 5 | 5 |
| 80 | 0.38 | 009111:80:x | 5 | 5 |
| 90 | 0.43 | 009111:90:x | 5 | 5 |
| 102 | 0.48 | 009111:102:x | 5 | 5 |
| 110 | 0.52 | 009111:110:x | 5 | 5 |
| 115 | 0.54 | 009111:115:x | 5 | 5 |
| 120 | 0.57 | 009111:120:x | 5 | 5 |
| 127 | 0.60 | 009111:127:x | 5 | 5 |
| 130 | 0.61 | 009111:130:x | 5 | 5 |
| 140 | 0.66 | 009111:140:x | 5 | 5 |
| 152 | 0.72 | 009111:152:x | 5 | 5 |
| 160 | 0.75 | 009111:160:x | 5 | 5 |
| 170 | 0.80 | 009111:170:x | 5 | 5 |
| 180 | 0.85 | 009111:180:x | 5 | 5 |
| 203 | 0.95 | 009111:203:x | 5 | 5 |
| 225 | 1.06 | 009111:225:x | 5 | 5 |
| 254 | 1.19 | 009111:254:x | 5 | 5 |
| 280 | 1.31 | 009111:280:x | 5 | 5 |
| 305 | 1.43 | 009111:305:x | 5 | 5 |
Product Features
| Maximum Temperature | 90 °C |
| Minimum Wall Thickness | 1 mm |
| Diameter Range | 50-305 mm |
