Master-PUR HX Food A

Master PUR HX Food A

Heavy duty & permanently antistatic, food graded per EU 10/2011 & FDA, polyurethane hose; great for food & pharmaceutical industries.

Product Description

Master-PUR HX Food A

Material

• spiral: anti-rust spring steel wire (material no. 1.4310)
• wall: pure polyether polyurethane, food-grade (FDA), with non-migratory permanent antistatic agent
• wall thickness between spirals approx. 1.7 -2.1 mm depending
on DN

Applications

• pharmaceutical industry
• chemicals industry
• food industry

Properties

• Master-PUR HX Food A hose conforms with EU Guideline 10/2011
• approved for food-grade category: E (contact duration according to Test Report)
• the material of the wall complies with the FDA food regulations 21 CFR § 177.1680 and 21 CFR § 177.2600
• extremely abrasion-resistant via specific reinforcements underneath the spiral
• flexible
• heavy
• permanently antistatic, surface resistance < 109 Ohm
• approved acc. to TRGS 727 and ATEX 2014/34 EU. Details according to the certificate
• mostly smooth inner lining
• odourless/tasteless
• microbe and hydrolysis-resistant
• increased pressure and vacuum resistance
• halogen and plasticizer-free
• optimum flow characteristics
• good chemical resistance
• high tensile strength
• generally good UV and ozone resistance

Temperature Range

• -40°C to +90°C
• peaks to +125°C

Master PUR HX Food A Hose Data Sheet

Masterflex Chemical Resistance Sheet

DN op. pressure vacuum bend radius outer Ø weight/m old article no. new article no. standard
length
max. production length
bar bar mm mm kg m m
32* 4.85 0.94 80 42 0.66 114FA-032-x 000157-032-x 10 20
40* 4.27 0.94 100 50 0.83 114FA-040-x 000157-040-x 10 20
50* 4.02 0.94 123 60 1.02 114FA-050-x 000157-050-x 10 20
51* 4 0.94 125 61 1.04 114FA-051-x 000157-051-x 10 20
55* 3.75 0.89 140 65 1.1 114FA-055-x 000157-055-x 10 20
60* 3.6 0.89 150 70 1.2 114FA-060-x 000157-060-x 10 20
65* 3.3 0.89 165 75 1.29 114FA-065-x 000157-065-x 10 20
70* 3.15 0.89 175 80 1.38 114FA-070-x 000157-070-x 10 20
75* 2.96 0.89 188 86 1.57 114FA-075-x 000157-075-x 10 20
76* 2.92 0.89 190 87 1.61 114FA-076-x 000157-076-x 10 20
80* 2.77 0.89 200 93 1.93 114FA-080-x 000157-080-x 10 20
90* 2.4 0.89 225 103 2.16 114FA-090-x 000157-090-x 10 20
100* 2.15 0.87 246 113 2.53 114FA-100-x 000157-100-x 10 20
102* 2.1 0.87 250 115 2.6 114FA-102-x 000157-102-x 10 20
110* 1.95 0.87 275 124 2.82 114FA-110-x 000157-110-x 10 20
115* 1.8 0.87 290 129 2.94 114FA-115-x 000157-115-x 10 20
120* 1.65 0.87 300 134 3.07 114FA-120-x 000157-120-x 10 20
125* 1.65 0.87 310 138 3.33 114FA-125-x 000157-125-x 10 20
127* 1.65 0.87 315 140 3.44 114FA-127-x 000157-127-x 10 20
130* 1.65 0.84 325 145 3.54 114FA-130-x 000157-130-x 10 20
140* 1.5 0.83 350 153 3.81 114FA-140-x 000157-140-x 10 20
150* 1.5 0.82 433 165 4.08 114FA-150-x 000157-150-x 10 20
152* 1.5 0.82 450 167 4.13 114FA-152-x 000157-152-x 10 20
All data refers to a medium and ambient temperature of +20 °C.
* Available on request
Subject to technical changes and colour deviations.

Product Features

Maximum Temperature 90 °C
Minimum Wall Thickness 1.7 mm
Diameter Range 32-152 mm
