Ring Seal, for threaded sockets according to DIN 11851.
Product Description
Ring Seal
Material
• NBR, colour: white
Applications
• chemicals industry
• for application for connectors to machines and piping
• Sealing rings for screw connectors according to DIN 11851
• Sealing rings for solid, liquid and gaseous media in food, pharmaceutical and chemicals industries
Properties
• materials adhere to the food-grade regulations DIN 11851
• odourless/tasteless
• good chemical resistance
• can be steam-sterilized
• high tensile strength
Temperature Range
• -25°C to +120°C
• peaks to +150°C
| DS | inner Ø D | thickness S | old article no. gate | new article no. gate |
| mm | mm | |||
| 32 | 36 | 5 | 647-032-805 | 2461 |
| 40 | 42 | 5 | 647-040-805 | 2464 |
| 50 | 54 | 5 | 647-050-805 | 2467 |
| 65 | 71 | 5 | 647-065-805 | 2471 |
| 80 | 85 | 5 | 647-080-805 | 2475 |
| 100 | 104 | 6 | 647-100-805 | 2479 |
| 125 | 130 | 7 | 647-125-805 | 2482 |
| 150 | 155 | 7 | 647-150-805 | 2484 |
| All data refers to a medium and ambient temperature of +20 °C. Subject to technical changes and colour deviations. |
||||
Product Features
| Maximum Temperature | 120 °C |
| Diameter Range | 32-150 mm |
