Master Clip Iso NEOPRENE

Product Description

Master Clip Iso NEOPRENE:

Material

• clip profile spiral: hot-dip galvanised steel band
• wall: 2 ply Neoprene coated polyester fabric

Applications

• air-conditioning and ventilation systems
• engine manufacturing
• transport of hot and cold air
• suction of aggressive media
• automotive manufacturing
• low pressure range
• exhaust gas extraction
• chemicals industry

Properties

• outer chafing protection spiral
• increased temperature resistance
• vibration-proof
• high tension-proof connection of wall-lining and spiral via
• special clamp mechanism
• highly flexible
• Master-Clip Iso NEOPRENE is extremely compressible to approx. 1:3
• smallest bending radius
• good chemical resistance
• extremely lightweight

Temperature Range

• -35°C to +130°C
• peaks to +150°C

Master Clip Iso NEOPRENE Hose Data Sheet

Masterflex Chemical Resistance Sheet

DN	op. pressure	vacuum	bend radius	weight/m	old article no.	new article no.	standard length	max. production length
	bar	bar	mm	kg			m	m
76	0.62	0.25	45	0.8	231-075-x	007582-075-x	10	15
100	0.51	0.16	60	1.3	231-100-x	007582-100-x	10	15
125	0.33	0.1	75	1.4	231-125-x	007582-125-x	10	15
150	0.22	0.07	90	1.8	231-150-x	007582-150-x	10	15
200	0.15	0.04	120	2.4	231-200-x	007582-200-x	6	10
225	0.12	0.03	160	2.1	231-225-x	007582-225-x	6	10
250	0.1	0.02	180	2.3	231-250-x	007582-250-x	6	10
300	0.07	0.01	210	2.4	231-300-x	007582-300-x	6	10
All data refers to a medium and ambient temperature of +20 °C. *Available on request Subject to technical changes and colour deviations.
