Medium-Heavy Duty PU Suction hose & Transport Hose, very flexible, antistatic, microbe-resistant, hardly inflammable acc. to DIN 4102 B1
Product Description
Master Pur H Trivolution
Description
Master Pur H Trivolution, Abrasion Resistant Hose, is very flexible, highly abrasion-resistant, anti-static, with a smooth bore; it is good for transportation of grain, dust, powders, sugar, ice, salt, pneumatic conveying of abrasive media such as in agriculture and other industries:
• Abrasion Resistant Hose
• Polyester polyurethane hose / PU Ducting (microbe-resistant,hardly-inflammable & antistatic)
• Reinforced with embedded copper-coated high tensile steel wire helix
• PU thickness = 1.4mm
Properties
• Very flexible
• Highly abrasion-resistant
• Microbe resistant
• Hardly Inflammable to DIN4102 B1
• Antistatic Hoses (Anti-static, surface resistance < 10 to the 9 ohms)
• Nearly smooth bore
• Medium/heavy duty
• Improved pressure and vacuum characteristics over Master-Pur L
Applications
• Transportation of dust, powders, metal swarf, salt, sugar, ice, grain, etc.
• Pneumatic conveying of abrasive powders, granules and glass-filled materials
• Suction and wander sweeper hose for street cleaning machines
• Leaf collecting and grass cutting machines
Colour
Clear
Size Range
16 mm to 500 mm.
Temp Range
-40 ºC to +90 ºC (intermittent to +125 ºC).
Options
• Other lengths available on request
• A range of end fittings is available on request
Master PUR H Trivolution Hose Data Sheet
Download Masterflex Chemical Resistance Data Sheet
DN | op. pressure | vacuum | bend radius | outer Ø | weight/m | old article no. | new article no. | standard length |
max. production length |
bar | bar | mm | mm | kg | m | m | |||
13 | 4.7 | 0.92 | 38 | 19 | 0.15 | 111-013-x | 000063-013-x | 10 | 25 |
16 | 4.5 | 0.92 | 40 | 22 | 0.2 | 111-016-x | 000063-016-x | 10 | 25 |
20 | 4.3 | 0.92 | 43 | 26 | 0.22 | 111-020-x | 000063-020-x | 10 | 25 |
25* | 4.19 | 0.92 | 46 | 32 | 0.28 | 111-025-x | 000063-025-x | 10 | 25 |
26 | 4.16 | 0.92 | 47 | 33 | 0.29 | 111-026-x | 000063-026-x | 10 | 25 |
30 | 3.25 | 0.92 | 51.3 | 39.2 | 0.32 | 111-030-x | 000063-030-x | 10 | 25 |
32 | 3.25 | 0.92 | 60 | 41 | 0.39 | 111-032-x | 000063-032-x | 10 | 25 |
38 | 3.12 | 0.82 | 69 | 47 | 0.46 | 111-038-x | 000063-038-x | 10 | 25 |
40 | 3 | 0.82 | 72 | 49 | 0.49 | 111-040-x | 000063-040-x | 10 | 25 |
45 | 2.95 | 0.81 | 80 | 55 | 0.55 | 111-045-x | 000063-045-x | 10 | 25 |
50* | 2.82 | 0.82 | 86 | 60 | 0.66 | 111-050-x | 000063-050-x | 10 | 25 |
51 | 2.9 | 0.82 | 87 | 61 | 0.71 | 111-051-x | 000063-051-x | 10 | 25 |
55 | 2.75 | 0.76 | 95 | 65 | 0.77 | 111-055-x | 000063-055-x | 10 | 25 |
60 | 2.55 | 0.74 | 102 | 70 | 0.84 | 111-060-x | 000063-060-x | 10 | 25 |
63 | 2.49 | 0.71 | 106 | 72.6 | 0.87 | 111-063-x | 000063-063-x | 10 | 25 |
65 | 2.4 | 0.66 | 112 | 75 | 0.91 | 111-065-x | 000063-065-x | 10 | 25 |
70 | 2.25 | 0.66 | 117 | 80 | 0.97 | 111-070-x | 000063-070-x | 10 | 25 |
75* | 2.05 | 0.63 | 125 | 85 | 1.05 | 111-075-x | 000063-075-x | 10 | 25 |
76 | 2 | 0.59 | 126 | 87 | 1.06 | 111-076-x | 000063-076-x | 10 | 25 |
80 | 2 | 0.59 | 132 | 91 | 1.11 | 111-080-x | 000063-080-x | 10 | 25 |
90 | 1.65 | 0.52 | 149 | 101 | 1.25 | 111-090-x | 000063-090-x | 10 | 25 |
100* | 1.54 | 0.45 | 163 | 110 | 1.43 | 111-100-x | 000063-100-x | 10 | 25 |
102 | 1.5 | 0.44 | 165 | 112 | 1.48 | 111-102-x | 000063-102-x | 10 | 25 |
110 | 1.35 | 0.46 | 179 | 121 | 1.61 | 111-110-x | 000063-110-x | 10 | 25 |
115 | 1.35 | 0.31 | 186 | 126 | 1.68 | 111-115-x | 000063-115-x | 10 | 25 |
120 | 1.3 | 0.31 | 194 | 131 | 1.75 | 111-120-x | 000063-120-x | 10 | 25 |
125* | 1.3 | 0.31 | 201 | 136 | 1.89 | 111-125-x | 000063-125-x | 10 | 25 |
127 | 1.3 | 0.31 | 203 | 138 | 1.91 | 111-127-x | 000063-127-x | 10 | 25 |
130 | 1.3 | 0.31 | 209 | 141 | 1.96 | 111-130-x | 000063-130-x | 10 | 25 |
140 | 1.05 | 0.26 | 224 | 151 | 2.11 | 111-140-x | 000063-140-x | 10 | 25 |
150* | 1.05 | 0.26 | 240 | 161 | 2.31 | 111-150-x | 000063-150-x | 10 | 25 |
152 | 1.05 | 0.26 | 242 | 163 | 2.29 | 111-152-x | 000063-152-x | 10 | 25 |
160 | 0.9 | 0.25 | 255 | 171 | 2.51 | 111-160-x | 000063-160-x | 10 | 25 |
170 | 0.9 | 0.18 | 270 | 181 | 2.67 | 111-170-x | 000063-170-x | 10 | 25 |
175* | 0.9 | 0.18 | 278 | 186 | 2.74 | 111-175-x | 000063-175-x | 10 | 25 |
180 | 0.75 | 0.18 | 285 | 191 | 2.82 | 111-180-x | 000063-180-x | 10 | 25 |
200* | 0.75 | 0.18 | 316 | 212 | 3.42 | 111-200-x | 000063-200-x | 10 | 25 |
203 | 0.75 | 0.18 | 321 | 215 | 3.5 | 111-203-x | 000063-203-x | 10 | 25 |
225 | 0.6 | 0.12 | 353 | 237 | 3.65 | 111-225-x | 000063-225-x | 10 | 25 |
250 | 0.6 | 0.12 | 390 | 263 | 3.91 | 111-250-x | 000063-250-x | 10 | 25 |
254* | 0.58 | 0.12 | 396 | 267 | 3.91 | 111-254-x | 000063-254-x | 10 | 25 |
275* | 0.45 | 0.12 | 426 | 288 | 4.22 | 111-275-x | 000063-275-x | 10 | 25 |
280* | 0.45 | 0.12 | 435 | 293 | 4.3 | 111-280-x | 000063-280-x | 10 | 25 |
300 | 0.45 | 0.12 | 465 | 313 | 4.94 | 111-300-x | 000063-300-x | 10 | 20 |
315* | 0.45 | 0.12 | 488 | 328 | 5.19 | 111-315-x | 000063-315-x | 10 | 20 |
325* | 0.45 | 0.12 | 503 | 338 | 5.35 | 111-325-x | 000063-325-x | 10 | 20 |
350 | 0.45 | 0.12 | 540 | 363 | 6.96 | 111-350-x | 000063-350-x | 10 | 20 |
375* | 0.3 | 0.07 | 580 | 388 | 7.45 | 111-375-x | 000063-375-x | 10 | 20 |
400 | 0.3 | 0.07 | 615 | 413 | 7.95 | 111-400-x | 000063-400-x | 10 | 20 |
450* | 0.3 | 0.07 | 690 | 463 | 8.94 | 111-450-x | 000063-450-x | 10 | 20 |
500* | 0.3 | 0.07 | 765 | 513 | 9.93 | 111-500-x | 000063-500-x | 10 | 20 |
All data refers to a medium and ambient temperature of +20 °C. * Available on request Subject to technical changes and colour deviations. |
Product Features
Maximum Temperature | 90 ºC |
Minimum Wall Thickness | 1.4 mm |
Diameter Range | 25-500 mm |
